CRS Concepts

The C3 Ticket Tracker enables the (semi-)automated recording, editing & release of multilingual videos. In order to complete a release successfully, certain project settings must be configured and a few of the state transitions must be operated manually:

User accounts can have different roles depending on what the user should be able to do:

• User - can cut and edit tickets
• Restricted - can only use already defined actions and can't define new actions
• Superuser - can edit profiles and (re)import fahrplan
• Admin

more details on https://github.com/crs-tools/tracker/blob/master/src/Config/AccessControl.php

One of the really good features of the C3 tracker is that propertyies are inherited through the hierarchy:

• Project settings (Conference or Series)

  • Meta ticket (Parent with Fahrplan-ID & -Metadata)
    • Recording ticket (Language, etc)
      1. Main encoding ticket (MP4)
      2. additional encoding tickets, e.g. WebM, MP3, Opus, SD formats, etc.

For each ticket type, the tracker has a predefined set of states, which can be enabled and disabled on an per project basis. Here is an example workflow with only one manual checking step:

This allows quite flexible pipelines, which are described in more detail in Project setup – for now lets focus on a typical one:

Let's look into the steps done by worker scripts

script-A-recording-scheduler.pl

Schedules and transitions tickets from scheduled via recording to recorded, optionally filters by room. Skips opt-out events, but does not perform any real task besides transitioning the recording ticket.

• Inputs: CRS ticket in scheduled state
• Outputs: Ticket moved to recording or skipped
• Notes: Uses CRS_ROOM, Record.StartedBefore, and Record.EndedBefore filters

The actual recording is done by a bundlewrap configured systemd unit on the encoder which writes TS-Schnipsel to /video/capture/<conference-acronym>/<room>/, which are rsynced to storage. The “Schipsel” file names include the room name and recording timestamp as follows:

  <room>-YYYY-MM-DD_HH-MM-SS.<extension>

script-B-mount4cut.pl

Mounts raw video segments via FUSE. Checks and sets cut marks, stores metadata like duration and framerate.

• Inputs: Ticket in recording → preparing state
• Outputs: FUSE mount created and cut marks optionally stored
• Notes: Supports DV and TS formats

see cutting

The cutting process requires the operator to set start and end marks, using MLT-Video-Editor like Shotcut/Kdenlive but tooling accepts frame numbers via CLI. If your player does not show frame numbers you can approximate with the formula seconds * 25 assumed you have 25 frames per second. Note that this means you cut per second not per frame!

• Usage video YT link (german)

• TODO: CCCamp15 Recording / Postprocessing integrieren

script-C-cut-postprocessor.pl

Validates cut marks, adds intro/outro clips if defined, and calculates cut durations. Fails tickets with incomplete data.

• Inputs: Ticket in cut state
• Outputs: Ticket in finialized state, updated with durations and metadata
• Notes: Verifies intro/outro file paths and presence

Naming for intro and outro, all in /video/intros/<conference-acronym>/:

• Intro <integer-event-id>.ts
• Outro: outro.ts

script-D-encoding.pl

Runs encoding tasks from job XML. Skips if Voctomix is detected. Supports VAAPI acceleration and logs execution times.

• Inputs: Ticket in ready to encode state, XML jobfile with ffmpeg commands
• Outputs: Encoded media file(s), ticket state updated to encoded
• Notes: Uses CRS::Executor and task-type detection

script-E-postencoding-auphonic.pl

Runs audio processing and remuxing. Can optionally delegate to Auphonic for audio leveling and rendering.

• Inputs: Ticket in encoded state
• Outputs: Ticket in postencoded state, media file (MP4, …) with updated audio tracks and metadata
• Notes: Supports audio hash checking and production reuse

see checking

script-F-postprocessing-upload.pl

Uploads processed files to the target via ssh from encoder/storage to releasing.c3voc.de. Can skip uploads based on host config.

• Inputs: Ticket in postprocessing state
• Outputs: Files pushed to publishing target
• Notes: Validates file presence, honors opt-out and skip-hosts

https://github.com/voc/voctopublish
